Belt Conveyer

Brief introduction
Belt conveyer is used to transfer materials continuously. It is widely used in mining, metallurgical and coal industry to transfer sand, lump material, or packaged material. In many situation, it Is a very important component of nonstandard machinery. The belt conveyers produced by BREAK-DAY can be operated in the circumstance temperature ranging from -20℃ to +40℃. The temperature of transferred material by this belt conveyer should be lower than 50℃.

Features
High capacity;
Long transferring distance;
Simple structure;
Easy Maintenance;







Technical Data

Model	belt width (mm)	belt length (m) /power (Kw)			belt speed (m/s)	Capacity (t/h)
B500	500	≤12/3	12-20/4-5.5	20-30/ 5.5-7.5	1.3-1.6	45-100
B650	650	≤12/4	12-20/5.5	20-30/7.5-11	1.3-1.6	70-120
B800	800	≤10/4	10-15/5.5	15-30/7.5-15	1.3-1.6	120-180
B1000	1000	≤10/5.5	10-20/7.5-11	20-40/11-12	1.3-2.0	160-250
B1200	1200	≤10/7.5	10-20/11	20-40/15-30	1.3-2.0	200-400
